Noshok Level Transmitters

Industrial submersible level transmitters from NOSHOK are built to endure the most demanding environments. NOSHOK's product line includes a submersible level transmitter with a tiny diameter (0.97") that is ideal for hydrostatic level measurement in small diameter boreholes and wells. For battery-powered applications, the available sensor delivers low-power output signals as well as a temperature output. A cage-protected level transmitter is also available, which is excellent for severe conditions like sludge, slurries, tank monitoring, water, and wastewater.

NOSHOK also has an inherently safe submersible level transmitter for use in hazardous areas including water, wastewater, and wellhead monitoring. This sensor is FM and CSA approved.




611 Series Small Diameter Submersible Level Transmitters

NOSHOK 611 Series Submersible hydrostatic level transmitter is used for applications including boreholes and wells with small diameters (outer diameter 0.87"). Available with low power output signals for battery-powered applications and optional temperature output. This model has CE compliant to suppress RFI, EMI, and ESD. Widely used for applications including wellhead measurement, groundwater monitoring, level measurement in open bodies of water, sewage lift and pumping stations, setting ponds, and rainwater.


More details

612 Series Submersible Level Transmitters

NOSHOK 612 Series is a submersible 2-wire hydrostatic level transmitter with current and voltage output.  Available pressure range up to 1000 Psig and with accuracy ± 0.25% full scale (BFSL) or optional ± 0.125% full scale (BFSL) including the effects of non-linearity, hysteresis, non-repeatability, zero point, and full-scale errors. Also have CE compliant to suppress RFI, EMI, and ESD. Can be used in almost all applications including irrigation, tank monitoring, water & wastewater, and wellhead measurement.


More details

613 Series Cage-Protected Submersible Level Transmitters

NOSHOK 613 Series Cage-Protected Submersible Level Transmitters was designed for applications such as lift stations, sewage, slurry tanks, storm canals, water & wastewater, and wet wells. It is a 2 wire transmitter available with Current & voltage outputs. Also have CE compliant to suppress RFI, EMI, and ESD.


More details

627 Series Intrinsically Safe Submersible Liquid Level Transmitters

NOSHOK 627 Series is an Intrinsically Safe Submersible Liquid Level Transmitters with current output and pressure range up to 350 Psig. Built with standard accuracy of ±0.25 % full scale (BFSL) and an optional ±0.125% full scale (BFSL), for ranges ≥ 150 inH2O which includes the effects of non-linearity, hysteresis, non-repeatability, zero point, and full-scale errors. Approved by Canadian Standards Association and has CE compliant to suppress RFI, EMI, and ESD. Use is different kinds of applications such as irrigation, tank monitoring, water & wastewater, and wellhead measurement.


More details

20 Series Intelligent Silo & Tank Level Sanitary Pressure Transmitters

NOSHOK 20 Series Intelligent Silo & Tank Level Sanitary Pressure Transmitters was designed for hygienic applications such as food & beverage, dairy, chemical processing, and pharmaceutical. Available with Hart® protocol output and built with <0.1%/year stability. Consists of a strong flush diaphragm with minimal fill volume. Can be cleaned-in-place (CIP) or steamed-in-place (SIP) and meet 3A requirements.



More details
