• Power Efficiency: Operates entirely on the 4-20mA loop current, eliminating the need for external power.
• Compatibility: Works seamlessly with various flowmeter types like differential pressure, Coriolis, and electromagnetic, thanks to its 4-20mA input.
• Customization: Offers programmable settings for linear or square law input relationships, span, cut-offs, and conversion factors, allowing for precise flow calculations specific to your application.
• Reliable Memory: Non-volatile memory ensures all settings and totalized flow data are retained even during power outages.
• Engineering Unit Display: Program the flow rate, resettable total, and accumulated total to be displayed in your preferred engineering units for clear and easy interpretation.

• Rugged Design: The 102A boasts a weatherproof IP67 (NEMA 4X) polycarbonate enclosure, making it ideal for harsh outdoor environments.
• User-Friendly Interface: A tactile keyboard provides intuitive control for programming and operation.
• Mounting Options: Comes standard with a wall mounting bracket, with a 2-inch pipe mounting bracket available for additional flexibility.

• The 102A includes built-in high and low flow rate alarms for real-time monitoring.
• The high alarm output can be programmed to generate a scaled pulse signal proportional to the total flow, enabling further data analysis or integration with control systems.

• Powered by a 4-20mA Loop
• Displays Rate, Total and Accumulated Total
• Watertight to IP67 (Nema 4X)
• Wall and Pipe, Panel Mounting
• Fully Programmable
• CE Compliant

• Battery Powered: Operates entirely on internal, replaceable batteries, making it ideal for remote locations or applications lacking a permanent power source.
• Flowmeter Compatibility: Works with a wide range of flowmeter types, including turbine, positive displacement, electromagnetic, and Coriolis, thanks to its ability to handle pulse/frequency signals.
• Enhanced Accuracy: A 10-point linearization curve can be programmed to improve the accuracy of flow measurements specific to your application.
• Customization: Offers programmable settings for frequency cut-off and conversion factors. This allows you to convert flow rate (e.g., liters per second) to totalized values in different engineering units (e.g., tons).
• Data Retention: Non-volatile memory ensures all programmed settings and totalized flow data are retained even when the battery is replaced.
• User-Friendly Display: Program the rate of flow, resettable total, and accumulated total to be displayed in your preferred engineering units for clear and easy interpretation.

• Linearised Input
• Fully Programmable
• Displays Rate, Total and Accumulated Total
• Powered by Long-life Replaceable Batteries
• Panel, Wall and Pipe Mounting
• Watertight to IP67 (Nema 4X)
• CE Compliant

• DC Powered: Eliminates the need for external AC power by operating on a user-supplied 9-28 Volt DC source. This makes it ideal for remote locations or applications without readily available AC outlets.
• Intrinsically Safe Option: For hazardous environments, a certified intrinsically safe version (Model 202D) is available, ensuring safe operation.
• Flowmeter Compatibility: Works seamlessly with turbine, positive displacement, and paddlewheel flowmeters, offering flexibility for different flow measurement technologies.
• Ideal Applications: Well-suited for monitoring irrigation systems, pipelines, and as a replacement for traditional mechanical registers.
• High Accuracy: Delivers precise flow rate and totalization data.
• User-Friendly Interface: Features a tactile keyboard for intuitive programming and configuration.
• Rugged Construction: Boasts a weatherproof IP67 (NEMA 4X) polycarbonate enclosure, making it resistant to harsh outdoor conditions.
• Mounting Flexibility: Comes standard with a wall mounting bracket, with optional panel and pipe mounting brackets available for versatile installation options.
• Data Retention: Lithium batteries ensure programmed settings and totalized flow data are retained even during power interruptions.

• Displays Rate, Total and Accumulated Total
• DC Powered
• Watertight to IP67 (Nema 4X)
• Wall or Pipe, Panel mounting
• Fully programmable
• High and Low Flow Rate Alarms
• CE compliant
• Pulse Output

• No External Power Needed: Operates entirely on the loop current (4-20mA) from compatible flowmeters, eliminating the need for separate power supplies.
• Flowmeter Compatibility: Works seamlessly with turbine, positive displacement, and paddlewheel flowmeters, providing flexibility for various applications.
• Ideal Uses: Well-suited for monitoring irrigation systems, pipelines, and as a modern replacement for mechanical registers.
• Rugged Construction: Features a watertight IP67 (NEMA 4X) rated polycarbonate enclosure, making it ideal for harsh outdoor environments.
• Versatile Mounting: The 104D can be mounted directly on the flowmeter, on a panel, or on a wall using the included universal bracket. An additional 2-inch pipe mounting bracket is available for further installation options.
• User-Friendly Programming: Offers complete user control through the front panel. You can program:
  • K-factor (conversion factor for specific flowmeters)
  • Decimal point positions for desired level of detail
  • Filter constants to reduce measurement noise
  • Timebase for displaying flow rate (e.g., seconds, minutes)
• Clear Unit Display: Program the rate and total values to be displayed in your preferred engineering units (e.g., gallons per minute, barrels) for easy interpretation.

• Displays Rate, Total and Accumulated Total
• Loop DC powered
• Watertight to IP67 (Nema 4X)
• Wall or Pipe, Panel mounting
• Fully Programmable
• 4-20mA Output
• High & Low Flow Rate Alarms
• CE compliant
• Pulse Ouput

• Frequency or Analog Inputs: It seamlessly integrates with a wide range of flowmeters, handling both frequency and analog mass flow signals.
• Signal Savvy: Capable of understanding diverse signals like millivolt signals, reed switches, Namur proximity switches, and pulse trains. The intuitive front panel simplifies program selection for your specific flowmeter.

• Beyond Flow Rate: Provides real-time flow rate along with resettable and accumulated totals for both volume and mass.
• Density Flexibility: Integrate live or fixed density values for accurate volume and mass conversions, catering to various fluid types.

• Analog Input Refinement: The 515 FC03 acts as your built-in data purifier, filtering and eliminating noise from analog signals for clear and reliable measurements.
• Advanced Processing: Offers functionalities like scaling, filtering, square law correction, and cutoff point application for fine-tuning your data acquisition.

Bonus Feature:

• Tailored to suit mass flowmeters
• Versatile “user value” available on main menu
• Programmable for either frequency or analog flow input
• Selection of second language and user tags
• RTC logging over 1000 entries at user-specified scheduled times
• Selection of Detail or Basic main menu to suit operator and application
• Programmable pulse width and scaling of pulse output
• 4-20 mA retransmission
• RS232 and RS485 or Ethernet (optional) serial ports
• Front panel adjustment of 8-24 V DC output voltage
• Modbus RTU, Printer and other serial port protocols
• Front panel adjustment of 8-24V DC output voltage
• Backlit display
